Fiziskie parametri | |
---|---|
Izmēri | 242 x 277 x 432 mm |
Svars | 9.1 kg |
Printeris | |
---|---|
Printeris | Termo un Termo pārnese (papildus) |
Izšķirtspēja | 203 or 300dpi |
Drukāšanas ātrums | 152 mm/sec |
Drukas platums | 104 mm |
Uzlīmes garums | 203 dpi: 157"/3,988 mm and 300dpi: 73"/1854 mm (optional) |
Sensori | Reflective, Transmissive |
Atmiņa | |
---|---|
Standarta | 128MB Flash, 128MB RAM |
Uzlīme | |
---|---|
Biezums | 0.076 mm - 0.25 mm |
Uzlīmes platums | 19.4 mm - 114 mm |
Uzlīmes garums | 991 mm max |
Pārneses lenta/Ribons | |
---|---|
Ārējais diametrs | 81 mm |
Lentas platums | 40 mm - 110 mm |
Ribbona uzstādīšana | Ribbon wound ink-side out |
Lentas garums | 450 m |
Lentas ruļļa pamatnes diametrs | 1.0" (25.4 mm) |
Papildus | |
---|---|
Rūpnīcā uzstādāmās papildus iespējas | Thermal Transfer Core-to-Core Ribbon Handling System Print head 300 dpi (12 dots/mm) A front mount, passive peel option, w/ no take-up spindle A front mount guillotine cutter Liner Take-Up for ZT230 only, rewinds entire 8" roll of liner (includes peel option) |
Papildus opcijas jau esošiem printeriem | Additional scalable and smooth bitmapped fonts available Print head 300 dpi (12 dots/mm) A front mount, passive peeler A front mount guillotine cutter Internal parallel port option ZebraNet 10/100 Print Server – supports 10/100 Ethernet networks internally integrated option that enables the use of ZebraLink Webview and Alert features ZebraNet n Printer Server – supports 802.11 a/b/g/n networks via an internally integrated option; Real Time Clock (RTC) –date/time for standalone applications Keyboard Display Unit (KDU) option – Enter variable data and retrieve stored forms for standalone applications (requires null modem adapter with DB9 serial cable) |
Komunikācijas | Capabilities ZebraNet® 10/100 Print Server – supports 10/100 Ethernet networks internally integrated option that enables the use of ZebraLink Webview and Alert features ZebraNet® n Printer Server – supports 802.11 a/b/g/n networks via an internally integrated option |
Svītru kodi | |
---|---|
Svītrkodi | Linear bar codes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code 2-dimensional bar codes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec |
Programmēšana | |
---|---|
Metode | XML, ZPL I/ZPL II |
